A vehicle position sensor integrated with a weighbridge is a system designed to accurately detect and monitor the position of a vehicle on a weighing platform. This ensures that the vehicle is properly aligned during weighing, eliminating errors due to partial loading or misplacement. The system enhances accuracy, efficiency, and automation in weighing operations at industrial sites, logistics hubs, and toll plazas.
The weighbridge uses load cells to measure the total weight of a vehicle. To ensure the accuracy of this reading, the vehicle must be correctly positioned on the platform. The vehicle position sensor detects whether the vehicle is fully within the weighing zone before the system captures the weight data.
Position detection can be achieved through:
- Infrared (IR) sensors or ultrasonic sensors placed at the ends of the weighbridge.
- Laser distance sensors to detect vehicle entry and exit points.
- Inductive loop detectors embedded in the surface to sense vehicle presence.
Applications
- Industrial weighbridges for trucks and trailers
- Mining and construction vehicle weighing systems
- Automated toll collection systems
- Smart logistics and transport hubs
When the vehicle enters the platform:
- Entry sensors detect the front wheels.
- When both front and rear sensors are triggered, the system confirms full positioning.
- The weighbridge system automatically captures the weight data once stability is achieved.
- If the vehicle is not properly positioned, a signal or alert prevents weighing and notifies the operator.
Components
- Load cells (for weight measurement)
- IR / Ultrasonic / Laser sensors (for vehicle positioning)
- Microcontroller or PLC (for data processing)
- Signal conditioning circuits
- Display unit or operator console
- Communication interface (RS232 / Ethernet / wireless)
Advantages
- Prevents inaccurate weight readings due to improper positioning.
- Enables automatic weighing operations, reducing human error.
- Increases throughput and operational efficiency.
- Supports data logging and integration with ERP or logistics systems.
